- 22 -
[Model L30, BC30]
1. Loosen the knob and remove the air filter cover.
2. Twist the high tension lead boot on the spark plug
back and forth a couple of times to loosen the boot,
then pull the boot off of the spark plug.
3.
Loosen the knob and lift off the cylinder cover.
4. Clean all dirt and debris from the cooling fins and
from around the cylinder base.
5. After cleaning, reinstall the cylinder cover and
the high tention lead boot.
[Model L45, BC45, BC50]
1. Loosen the knob and remove the air filter cover.
2. Loosen the knob and lift off the cylinder cover.
3. Clean all dirt and debris from the cooling fins and
from around the cylinder base.
4.
After cleaning, reinstall the cylinder cover.
Knob
Cylinder Cove
To Next Page
