TONEOHM 950 OPERATOR MANUAL
2-2
Power cord colour codes are as follows:
Europe
BROWN LIVE
BLUE NEUTRAL
GREEN/YELLOW EARTH (GROUND)
United States
BLACK LIVE
WHITE NEUTRAL
GREEN GROUND
Check that the TONEOHM 950 mains switch (on the rear panel) is OFF.
Plug the power cable into the receptacle on the rear panel of the TONEOHM 950.
Plug the other end into a wall outlet.
2.3 Self test
When the instrument is switched on it performs a self test. During the self test the front panel LEDs are lit
in sequence. Do not operate front panel controls during the self test. If the test passes the instrument is
left in the 20V range.
