44
FEATURES AND CONTROLS
Instrument Cluster
Your ATV is equipped with an instrument cluster that senses vehicle
speed from t he right front wheel. The instrument cluster measures
distance in miles or kilometers as well as hours of operation. It also
includes a reverse speed limiter function that limits the ATV’s speed to
approximately 7-9 mph. Refer to page 33 for additional information.
1. Rider Information Center
2. Speedometer needle - in addition to showing vehicle speed, the
needle flashes when a warning condition exists.
3. Speedometer
CAUTION
To prevent damage, wash the ATV by hand or with a garden hose
using mild soap. Do not use alcohol to clean the instrument
cluster. Immediately clean off any gasoline that splashes on the
instrument cluster . Do not allow insect sprays to come into
contact with the lens.
2
3
1
