166
Specifications
SPORTSMAN 90
Front Tires 19 x 7 - 8 (3 psi/20.7 kPa)
Rear Tires 18 x 9.5 - 8 (3 psi/20.7 kPa)
Dry Weight 289 lbs. (131 kg)
Length/Width/Height 61.75" (157 cm) / 36.75" (93 cm) / 38.5" (98 cm)
Wheel Base 41.5" (105 cm)
Ground Clearance 4" (10 cm) at swing arm, 7.7" (19.5 cm) at frame
Brake Light Standard
Daytime Running Lights Standard
Carburetor Settings
Cutaway n/a
Pilot Air Screw 1.25 turns out
Needle Jet 11
Pilot Jet 40
Main Jet 80
E-Clip Position #4 from top
