Page 31
English
2
Figure 29. Undo the Tabs of the Brush
3. To install the new brush, position the new brush on the roller with the
cleaning blades facing away from the roller (Figure 30).
3
Figure 30. Install the New Brush
4. Thread each tab into the slot provided and gently feed it through until
the heel comes out at the other side of the slot (Figure 31).
4
Figure 31. Pull Tabs Through Each Slot
