Polaris Quattro Instructions For Installation And Use

9
3.1.1 If the water fl ow rate is insuffi cient (under 28 rpm)
• Check the in-line filter assembly ( ) and remove debris, see "4.2 I Cleaning the in-line fi lter screen".
• Check the hoses and connectors looking for leaks that could cause a loss of water pressure.
• Check the swivels ( ) looking for leaks or excessive spray. Check that the arrow showing the direction of water flow
( ) is correctly pointed towards the cleaner.
• Before performing the following checks, make sure the booster pump and filter pump are off.
• Clean the skimmer, filter and basket of the pump by removing any debris.
• Remove the blue restrictor disc (
) from the universal wall fitting (UWF®) connector ( ), see "2.3 I Connec ng the
hose to the wall fi  ng".
3.1.2 If the water fl ow rate is too high (over 32 rpm)
• Before performing the following checks, make sure the booster pump and filter pump are off.
• Replace the blue restrictor disc with the red restrictor disc (
).
• Loosen the pressure relief valve until the wheel speed is between 28 and 32 rpm.
• The pressure relief valve must only be adjusted if a restrictor is installed.
1
EN

Polaris Quattro Specifications

General

Type	Robotic
Pool Type	In-ground
Cleaning Coverage	Floor, Walls, and Waterline
Drive Mechanism	4-Wheel Drive
Warranty	2 years
Cable Length	60 ft
Hose Length	Not applicable (robotic)
Debris Intake	Large capacity
