Polaris Quattro Instructions For Installation And Use

7
2.5 I Installing the connector on the hose
• Place the nut ( ) on the end of the connector ( ), see image .
• Push the hose into the connector, see image . Water can be used to lubricate the hose.
• Firmly  ghten the nut around the hose, see image .
i
i
i
i
2.6 I Connec ng the hose to the cleaner and posi oning the fl oats
• Push the connector ( ) into the cleaner. Rotate in the clockwise direc on to lock in posi on.
• Posi on the fi rst hose fl oat ( ) against the connector.
• Slide the fl oats along the hose to posi on them. The recommended distance between each fl oat is between 30 and
90 cm, see "1.2.3 Hose parts list".
EN

Polaris Quattro Specifications

General

Type	Robotic
Pool Type	In-ground
Cleaning Coverage	Floor, Walls, and Waterline
Drive Mechanism	4-Wheel Drive
Warranty	2 years
Cable Length	60 ft
Hose Length	Not applicable (robotic)
Debris Intake	Large capacity
