Polaris Quattro Instructions For Installation And Use

8
❸ Use
3.1 I Checking the op mum speed of wheel rota on
Before turning on the cleaner, check that the speed of wheel rotation (rpm) is correct. For optimum efficiency, the
cleaner must perform between 28 and 32 revolutions/minute. Keep the cleaner immersed in the pool in order to
accurately count the number of wheel rotations.
• Turn on the filter pump and leave to prime.
• Turn on the booster pump; the cleaner will start to move.
• With the two pumps running, pull on the hose to bring the cleaner to the waterline.
• Hold the cleaner using the handle to keep it submerged.
• Always li the cleaner using the handle and take care to avoid possible hair entanglement when
leaning over.
• The lid opening bu on showing the Polaris® logo is not a handle.
• Use the Polaris® logo on the front left wheel as a marker to count the number of full revolutions made by the wheel
in one minute. If the wheels change direction during the count, start again.
• If the speed of wheel rotation does not reach the desired interval of between 28 and 32 rpm, follow steps "3.1.1 If the
water fl ow rate is insuffi cient (under 28 rpm)" or "3.1.2 If the water fl ow rate is too high (over 32 rpm)".
Revolu ons/
minute
Keep the cleaner immersed in
the pool in order to accurately
count the number of wheel
rota ons.
Number of
revolu ons/minute
< 28
28 < 32
> 32
Insuffi cient water fl ow rate, see "3.1.1 If the water fl ow rate
is insuffi cient (under 28 rpm)"
Water fl ow rate okay,
Water fl ow rate too high, see "3.1.2 If the water fl ow rate is
too high (over 32 rpm)"

Polaris Quattro Specifications

General

Type	Robotic
Pool Type	In-ground
Cleaning Coverage	Floor, Walls, and Waterline
Drive Mechanism	4-Wheel Drive
Warranty	2 years
Cable Length	60 ft
Hose Length	Not applicable (robotic)
Debris Intake	Large capacity
