Polaris RANGER 570 EPS 2016 - Page 499

9
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
9.37
NUMBER DESCRIPTION
TORQUE (IF APPLICABLE)
h
Bolt - M10 x 1.25 x 20 (QTY.8) 28 ft-lb (38 Nm)
j
Bolt - M8 x 1.25 x 20 (QTY.4) 17 ft-lb (23 Nm)
k
Nut - 5/16 – 18 (QTY.2) —
l
Nut - M8 x 1.25 (QTY.2) 15 ft-lb (20 Nm)
1(
Clevis Pin - 5/16 x 1 (QTY.1) —
2)
Clip, Clevis Pin —
2!
Clevis Pin - 1/4 x 3/4 (QTY.1) —
2@
Push Rivet (QTY.4) —
2#
Clip, Silencer —
BRAKE SYSTEM
