100
MAINTENANCE
Lights
Headlight Beam Adjustment
1. Place the vehicle on a level surface with the headlight approxi-
mately 25 ft. (7.6 m) from a wall. Place the transmission in PARK.
2. Measure the distance from the floor to the center of the headlight
and make a mark on the wall at the same height.
3. Apply the brakes. Turn the ignition switch to the LIGHTS ON posi-
tion.
4. Observe the headlight aim. The most intense part of the headlight
beam should be aimed 8" (20 cm) below the mark placed on the
wall in step 2. Include the weight of a rider on the seat while per-
forming this step.
5. If adjustment is necessary, turn the headlight adjustment screw to
adjust the beam.
6. Repeat steps 4-5 until the beam is properly adjusted.
