92
MAINTENANCE
Throttle System
Throttle Body/Idle RPM
Idle RPM is preset by the manufacturer. If the engine idle speed is not
satisfactory, please see your POLARIS dealer for adjustment.
Throttle Freeplay Adjustment
1. Remove both seats. Remove
the engine access panel. See
page 28.
2. Locate the throttle cable
adjuster at the throttle body.
3. Slide the cable adjuster boot
off the cable adjuster.
4. Using a 10 mm open-end
wrench, loosen the adjust-
ment jam nut.
5. Using an 8 mm open-end
wrench, move the cable
adjuster until 1/16" to 1/8"
(1.5-3 mm) of freeplay is
achieved at the throttle pedal.
See page 91. While adjusting,
lightly flip the throttle pedal
up and down.
6. Tighten the jam nut.
7. Apply a small amount of grease to the inside of the boot and slide it
over the cable adjuster to its original position.
