114
SPECIFICATIONS
RANGER RZR 570
Gross Vehicle Weight 1719 lbs. (780 kg)
Dry Weight 962 lbs. (436 kg) Base Model
999 lbs. (453 kg) LE Model
Rear Cargo Box Capacity 300 lbs. (136 kg)
Maximum Weight Capacity
(Payload)
740 lbs. (336.4 kg) (riders/cargo/accessories/
trailer tongue weight)
Receiver Hitch Tongue Capacity 150 lbs. (68 kg)
Receiver Hitch Towing Capacity 1500 lbs. (680 kg
Fuel Capacity 7 gal. (26.5 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant System Capacity 4 qts. (3.76 l) excluding coolant bottle
Coolant Bottle Capacity 8 oz. (237 ml)
Demand Drive Fluid Capacity 6.75 oz. (200 ml)
Transmission Oil Capacity 24 oz. (710 ml)
Overall Length/Width/Height 107.5/50/69 in. (273/127/175.3 cm)
Wheelbase 77 in. (196 cm)
Ground Clearance 10 in. (25.4 cm)
Engine Dual overhead cam, 4 valve 4 stroke single
cylinder
Displacement 567 cc
Bore x Stroke 99mm x 73.6mm
Alternator Output 650 W @ 7000 RPM
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System ECU
Spark Plug / Gap RG4YCX / 0.7-0.8 mm
Front Suspension Independent double a-arm with 9 in. (23 cm)
travel
Rear Suspension Independent double a-arm with 9.5 in. (24 cm)
travel
