101
MAINTENANCE
Filter Systems
Air Filter
Always change the air filter at the intervals outlined in the Periodic
Maintenance Chart beginning on page 75.
1. Access the air box
from behind the left
rear wheel.
2. Remove the air box
cover and inspect the
gasket. It should
adhere tightly to the
cover around the
entire edge.
3. Remove the air filter.
4. Remove the pre-filter
from the main air
filter.
5. Wash the pre-filter in
soapy water, then
rinse and let dry.
NOTE: Install a new main filter if needed. Do not attempt to clean the main air
filter.
6. Reinstall the pre-filter over the main filter.
NOTE: Apply a small amount of general purpose grease to the sealing edges
of the filter before installing.
7. Inspect the air box for oil or water deposits. If present, drain them
into a suitable container.
Pre-Filter
Air Box Cover
Air Filter
Gasket
To Next Page
