104
MAINTENANCE
Throttle System
Throttle Body/Idle RPM
Idle RPM is preset by the manufacturer. If the engine idle speed is not
satisfactory, please see your Polaris dealer for adjustment.
Throttle Freeplay Adjustment
1. Remove both seats.
Remove the rear service
panel. See page 35.
2. Locate the throttle cable
adjuster.
3. Squeeze the end of the rub-
ber boot and slide it far
enough to expose the end
of the inline cable adjuster.
4. Loosen the adjuster lock
nut.
5. Rotate the boot to turn the
adjuster until 1/16" to 1/8"
(1.5-3 mm) of freeplay is
achieved at the throttle
pedal. See page 103.
NOTE: While adjusting, lightly flip the throttle pedal up and down.
6. Tighten the lock nut.
7. Squeeze the end of the rubber boot and slide it over the cable
adjuster to its original position.
Boot
Adjuster
Lock Nut
To Next Page
