126
SPECIFICATIONS
RANGER RZR
Gross Vehicle Weight 1727 lbs. (783 kg)
Dry Weight 945 lbs. (429 kg)
Fuel Capacity 7 gal. (26.5 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 4.8 qts. (4.5 l)
Rear Gearcase Oil Capacity 18 oz. (532 ml)
Demand Drive Fluid Capacity 6.75 oz. (200 ml)
Transmission Oil Capacity 24 oz. (710 ml)
Transfer Case Oil Capacity 14 oz. (414 ml)
Front Storage Capacity 25 lbs. (11.3 kg)
Rear Cargo Box Capacity 300 lbs. (136 kg)
Maximum Weight Capacity
(Payload)
740 lbs. (336.4 kg) (riders/cargo/accessories)
Receiver Hitch Tongue Capacity 150 lbs. (68 kg)
Receiver Hitch Towing Capacity 1500 lbs. (680 kg
Overall Length 102 in. (259 cm)
Overall Width 50 in. (127 cm)
Overall Height 68.5 in. (174 cm)
Wheelbase 77 in. (196 cm)
Ground Clearance 10 in. (25.4 cm)
Engine 4 valve 4 stroke twin cylinder with
counterbalance
Displacement 760 cc
Bore x Stroke 80mm x 76mm
Alternator Output 500 W @ 3000 RPM
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System ECU
Spark Plug / Gap RC7YC /.035 in. (0.9 mm)
Front Suspension Independent double a-arm w/9 in. (23 cm) of
travel
Rear Suspension Independent double a-arm w/9.5 in. (24 cm) of
travel
