110
MAINTENANCE
Tires
Wheel Removal
1. Position the vehicle on a level surface.
2. Place the transmission in PARK. Stop the engine.
3. Loosen the wheel nuts slightly.
4. Elevate the side of the vehicle by placing a suitable stand under the
frame.
5. Remove the wheel nuts and washers. Remove the wheel.
Wheel Installation
1. Place the transmis-
sion in PARK.
2. Place the wheel in
the correct position
on the wheel hub.
Be sure the valve
stem is toward the
outside and rotation
arrows on the tire
point toward for-
ward rotation.
3. Attach the wheel
nuts and washers
and finger tighten.
4. Carefully lower the vehicle to the ground.
5. Torque the wheel nuts to specification. See page 109.
WARNING
Improperly installed wheels can adversely affect tire wear and vehicle
handling, which can result in serious injury or death. Always ensure that all
nuts are torqued to specification. Do not service axle nuts that have a cotter
pin installed. See your Polaris dealer.
