FEATURES AND CONTROLS
Cab Nets
Upper Cab Net Removal (Driver)
The upper cab net on the driver’s side may be removed only if it inter-
feres with operation of the vehicle. All other cab nets must remain
installed.
1. Using a T-25 torx bit and 7/16"
open end wrench, remove the
mounting screw and washers secur-
ing the upper and lower cab nets to
the floor of the vehicle on the
driver’s side.
2. Reinstall the lower net with the
screw and all washers. Tighten the
screw securely.
3. Unclip the four latches that secure
the upper net to the chassis and
lower net. See the photo on the pre-
vious page.
4. Clip the free upper latch of the
lower cab net to the free latch on
the shoulder net, adjusting strap
length as needed. Tighten the strap.
5. Reverse all steps to reinstall the cab
net.
NOTE: Always reinstall the upper cab net for any other operator of the vehicle.
Step 1
Screw
and
Washers
Step 2
To Next Page
