TRANSMISSION SERVICE
TRANSMISSION REMOVAL
WARNING
Serious injury may result if machine tips or falls. Be
sure machine is secure before beginning this
procedure. Always wear eye protection.
1. Disconnect the (-) negative battery cable from the
battery.
2. Remove the nine screw for the dog house cover over
the air box.
3. Loosen the clamp
q
for the PVT intake.
4. Remove the four screws mounting the engine and
PVT intake vents.
5. Remove the two bolts
w
retaining the air box to the
frame support and loosen the clamp from the air box
to the intake.
6. Remove the 22 cargo box mounting screws.
