9.36
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
For DX bushing and seal style eyelet, follow the removal
procedures below.
1. Remove both dust seals from the eyelet.
2. Press out DX bushing using DX Bushing Press Kit
(803-00-935).
NOTICE
DX Bushing style eyelets have larger bore diameters
than conventional eyelets.
3. Remove dust seal from bearing cap.
NOTICE
On some models the seal may be in the bearing
assembly.
4. Remove low friction seal pack from bearing
assembly.
5. Remove U-Cup seal from bearing assembly. Note the
direction seal was installed.
STEERING / SUSPENSION
