7. Use two open-end wrenches and loosen the outer
jam nut
w
. Back out the outer jam nut 1 1/2 turns.
8. Hold the outer jam nut and turn in the inner jam nut
e
clockwise, until the jam nut is tight against the
bracket.
9. Repeat Step 3 and Step 4 until the proper
adjustment is obtained for the parking brake.
10. If additional adjustment is needed, the cable can be
adjust on the parking brake handle side jam nut
r
.
BRAKE SYSTEM
