GENERAL INFORMATION
1.7
MODEL: 2003 TRAIL BOSS 330............
MODEL NUMBER: A03CA32...
ENGINE MODEL: ES32PFE10....
ELECTRICAL FLUID Capacity Type
Flywheel I.D. None Fuel Tank 3.25 gals. (12.30 L)...... ..........
CDI Part Number 4010697 Transmission 11.3 oz. (335 ml) PPS*... .......
Alternator Output 210 watts Engine Oil 1.5 qts (1.4 L) PP4*... .........
Ignition Timing 30°±2° BTDC@5000RPM Brake (Hand) Dot 3..... .....................
Spark Plug / Gap NGK BKR6E / 0.0362 (0.9 mm) Brake (Foot) Dot 3... ......................
Lights: Head (2) Dual Beam 30/30 watts......
Tail 8.26 watts........
Brake 26.9 watts......
Indicator 1.0 watts...
Electric Start Standard.......
Electronic Speedo N/A..
Polaris Lubricants
*PP6 Polaris Premium 60/40 Antifreeze/Coolant
*PPS Polaris Premium Synthetic Gear Case Oil
*PP4 Polaris 0W--40 Synthetic Engine Lubricant
*PDD Premium Demand Drive Hub Fluid
SUSPENSION / CHASSIS DRIVE TRAIN
Body Style Gen IV Chain Type 520 O-Ring........ .........
Front Suspension MacPherson Strut Gear Reduction-Rev 3.05/1.. .
Tow Capacity 850 lbs. (385.9 kg) Gear Reduction-High 2.68/1......
T urning Radius 752 (191 cm) Final Drive Ratio 11/40 78P..... ....
Toe Out 1/82-1/42 (3-6.35 mm) Brake (Hand) Single Lever, Hyd. Disc........... .......
Ground Clearance 5.52 (13.97 cm) Brake ( Auxiliary Foot) Hydraulic..
Front Vertical T ravel 6.72 (17.02 cm)
Rear Suspension Progressive Rate Swing Arm...
Rear Travel 9.02 (22.86 cm)........
Rear Shock 22 Gas Charged T win Tube........
Shock Adjustment Cam..
TIRES
T ire Size - Front 23 x 7 - 10....
T ire Size - Rear 22 x 11 - 10....
T ire Pressure - F/R 4/3 lbs..
Total W idth 462 (117 cm)........
Total Length 752 (191 cm).......
Total Height 462 (117 cm)........
Wheel Base 49.52 (125.73 cm).......
Weight - Dry 505 lbs. (230 kg).......
OPTIONAL SUSPENSION SPRINGS
SPRING TYPE SOFT STANDARD FIRM
Rear Compression Spring
N/A
7041518-067
130 --165 lb/in.
7041303-067
250 lb/in.
Front Strut Spring N/A 7041850-067
41 lb/in.
7041375-067
64 - 113 lb/in.
LOAD CAPACITY
Front Rack (Accy) 75 lbs. (34 kg)....
Rear Rack (Std) 125 lbs. (57 kg)......
Tongue Weight 85 lbs. (14 kg).......
Tow Hitch Std...........
