Chapter 3 Using the LCD TV
The PIP/POP feature allows simultaneous viewing of video from two sources (TV, VCR, DVD etc).
Only one source’s audio is played at a time; the user may select which source’s audio is heard.
Press the PIP button once to enter Picture-in-Picture mode.
Main
Sub
MAINSUB
Using Picture-In-Picture
▪ Press ◄ ► to toggle the audio source between the main window and
the sub window.
▪ Press the SWAP button to swap the pictures between the main and sub
windows.
▪ Press the OK button to change the position of the second window.
1
3
5
2
4
▪ Press ◄ ► to activate either the main or sub windows, then press the
SOURCE button to display the Input List:
Press ▲▼ to change input source and press the OK button.
Chapter 3
USING THE FEATURES
Sub
VIDEO5 (YPbPr)D
VIDEO6 (HDMI1)
VIDEO7 (HDMI2)
COMPUTER (VGA)
To Next Page
