Polaroid P420T

3.3.3 Loading the Media in Cutter Mode (Option)
Note:
Please calibrate the gap/black mark sensor when changing media.
1. Refer
to Chapter 3.3.1 to load the
label roll.
2
. Pull the label through the cutter
paper
opening.
3.
Close the print head mechanism and
printer
cover. Use the DiagTool to set
the
printer
for cutter mode by selecting
“CUTTER” option
for Post-Print Action
setting
then click “Set” button to enable
the
cutter mode. Press
the FEED button
to
test.
20
