Polimaster PM1603A User Manual

14
1.4 Design and theory of operation
1.4.1 The dosimeter comprises the following main blocks and modules:
- radiation detector;
- microprocessor;
- LCD;
- IR-transceiver;
- non-volatile memory.
The block diagram of the dosimeter is shown in Figure 1.1.
Figure 1.1 – Block diagram of the dosimeter
Backlight
driver
Quartz
generator
Microprocessor
IR-
transceiver
Battery
3 V
Radiation
detector
DAC
of temperature
compensaton
LCD
RAM
High voltage
power supply
Control
buttons
Audible
signal
