30
General
Channels All International Channels
Frequency Method PLL (Phase Lock Loop)
Frequency range
TX 156.025 ~ 157.425 MHz
RX 156.300 ~ 162.000 MHz
Antenna Impedance 50 ohm
Power Supply 7,4 Vcc
Operating Temperature -15°C ~ +55°C
Dimensions (h x w x d) 157 × 65 × 40 mm with battery
Weight 280 g with battery
Transmitter
Power Output 1 or 6 W (switch selectable)
Modulation Type FM
Hum and Noise Attenuation 40 dB
Audio Distortion 5%
Receiver
Sensitivity at 12dB SINAD 0,3 µV
Squelch sensivity Threshold –1 2 dB µV (EMF)
lntermodulation Rejection 70 dB
Audio Power Output
250mW a 5% THD
Hum and Noise Attenuation 40 dB
Note: data are are subject to variations
TECHNICAL SPECIFICATIONS
