Polycom SoundPoint IP 670 Quick Start Guide

SoundPoint IP Color Expansion Module Quick Start Guide
1. Remove the rubber plug that ships with the unit from the SoundPoint IP 670 phone or
from the Color Expansion Module.
2. Align the Expansion Module at the top of the groove lines on the SoundPoint IP 670
phone and slide unit downwards until unit clicks into position. Connect the Base
Stand for each Module.
3. To connect up to three Expansion Modules together, repeat steps 1 and 2.
Directories
Applications
Conference
Transfer
Redial
ABC
21
DEF
3
54
MNOJKLGHI
6
TUV
8
WXYZ
9
OPER
PQRS
0
7
Menu
Messages
Do Not Disturb
Hold
ABC
21
DEF
3
54
MNOJKLGHI
6
TUV
8
WXYZ
9
OPER
PQRS
0
7
Menu
Messages
Do Not Disturb
ABC
21
DEF
3
54
MNOJKLGHI
6
TUV
8
WXYZ
9
OPER
PQRS
0
7
Menu
Messages
Do Not Disturb
Directories
Applications
Conference
Transfer
Redial
ABC
21
DEF
3
54
MNOJKLGHI
6
TUV
8
WXYZ
9
OPER
PQRS
0
7
Menu
Messages
Do Not Disturb
Hold
Installation

Polycom SoundPoint IP 670 Specifications

General

Voice codecs	G.711, G.722, G.729
Noise reduction	Yes
Microphone frequency	150 - 7000 Hz
Caller ID	-
Phonebook capacity	- entries
Security algorithms	HTTPS
Supported network protocols	SNTP/FTP/TFTP/HTTP
Display resolution	320 x 160 pixels
Ethernet LAN (RJ-45) ports	2
Product type	IP Phone
Product color	Gray
Dimensions (WxDxH)	265 x 190 x 150 mm
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Certification	FCC, RoHS, CE
Harmonized System (HS) code	85171800

Weight and Dimensions

Weight	1260 g
