Polytec OFV-511 User Manual


)LUVW6WHSV
The back panel of the sensor head OFV-511 is shown in figure 3.6.
 7UDQVSRUWKDQGOH
 6HQVRUPR XQW
To transport the sensor head, the mini sensor can be plugged into this
sensor mount.
 6,* 1$/352&(6625 - connector (Sub-D jack)
Jack for the connecting cable to the controller
 7UDQVS RU W VDI HW \ PHF KDQ LV P
The transport safety mechanism is (de)activated by turning the screw with
the Allen key provided (refer to section 5.8).
Figure 3.6: Rear view of the sensor head OFV-511
8 7
SIGNAL
PRO CESSOR
ACHTUNG!
Bitte vor dem Transport
die Transportsicherung betätigen
CAUTION!
Please secure transport m echanism
before shipm ent
M EASUREM ENT
TRANSPORT
9
10
&DXWLR Q 
$OZD\V activate the transport safety mechanism EH IRU H moving the sensor head!
