)LUVW6WHSV
6HQVRU+HDG2)9
The back panel and the front panel of the sensor head OFV-353 are shown in
figure 3.4.
%HDP V KXW WH U
In position OFF the laser beam is blocked.
&21752//(5
- connector (Sub-D jack)
Jack for the connecting cable to the controller
6LJQDOOHYHOGLVSOD\
The length of the bar is a measure of the amount of light scattered back
from the surface of the object.
/$6(5
- L
ED
The L
ED
lights up when the laser is switched on (key switch on the control-
ler in position I) i.e. even if the beam shutter is closed (refer to
section 5.2).
Switch
%5$ .( 21 2))
This knob is used to fix the focus (refer to section 5.7).
)URQWOHQV
Exchange of the front lens is described in section 5.5.
)RFXVLQJULQJ
Focusing ring for focusing of the laser beam (refer to section 5.4)
Figure 3.4: Rear view and front view of the sensor head OFV-353
ON
OFF
BRAKE
8
5
6
7
3
2
1
4
EM ISSIO N
OFF
ON
CONTROLLER
LASER
S
I
G
N
A
L
:DUQLQJ
2QO\ switch the beam shutter to position ON when you are making measurements!
