)LUVW6WHSV
If the functional test has been successful you can now make measurements
as described in chapter 4.
If your vibrometer does not perform as described above, read through the
information on fault diagnosis provided in chapter 6 and, if necessary, contact
your local Polytec representative.
9LEURPHWHUZLWK6HQVRU+HDG2)9
For the installation and an initial functional test of the vibrometer, proceed as
follows:
3UHSDULQJ
1.
2QO\2)9
: Unscrew the mini sensor from the reference fiber. The ref-
erence fiber is marked with a red dot. Mount the reference head OFV-151
on the reference fiber as described in section 5.6.
2. Deactivate the transport safety mechanism on the back of the sensor
head by turning the screw with the Allen key provided to position
MEASUREMENT (refer to section 5.8).
3. Make sure that the key switch on the controller is in position O.
4. Check the setting on the mains voltage selector on the back of the control-
ler as well as the fuses.
&DEOLQJ
5. Plug the connecting cable into the Sub-D jack SIGNAL PROCESSOR on
the back of the sensor head and into the Sub-D jack INTERFEROMETER
on the back of the controller. Fix the connections with the screws pro-
vided.
$OOFRQQHFWLRQVPXVWEHHDV\WRSOXJLQ,IQRWFKHFNWKHSOXJIRUEHQW
FRQWDFWSLQVWRDYRL GVHULRXVGDPDJHEHLQJLQFXUUHG
6. Use the earthed mains cable to connect the controller to a wall outlet pro-
viding protective grounding.
6ZLW FKLQJ RQ
7. Switch the controller on by turning the key switch to position I.
2QWKHIURQWRIWKHFRQWUROOHUWKH/
('
32:(5OLJKWV XS3URYLGLQJWKH
FRQQHFWLQJFDEOHKDVEHHQLQVWDOOHGFRUUHFWO\WKH/
('
67$1'%<RQWKH
VHQVRUKHDGDOVROLJKWVXS/DVHUOLJKWLVQRW\HWHP LWWHGDVWKHEHDP
VKXWWHULVVWLOOFORVHG
8. Before now opening the beam shutter, remember the information on laser
safety provided in section 1.1!
9. Open the beam shutter on the sensor head by pressing the key LASER on
the front of the sensor head.
7KH/
('
21RQWKHVHQVRUKHDGOLJKWVXS$WW KHVDPHWLPHWKH/
('
67$1'%<JRHVRXW7KHODVHUEHDPLVQRZHPLW WHGIURPW KHPLQLVHQ
VRU
7HVW
10. Put a piece of reflective film (enclosed in this manual) at approximately
12cm from the front lens of the mini sensor in the beam path.
