2SHUDWLQJWKH9LEURPHWHU
0HQX
6(77, 1*6
In the menu SETTINGS the measurement ranges and filters are set. The con-
tents of the menu depends on the decoders installed. The individual settings
are described in the following.
7UDFNLQJ)LOWHU
In this line you can set the tracking filter. The input signal from the sensor
head is pre-processed with the tracking filter. You will find information on the
settings
2))6/2:
/
)$67
of the tracking filter in section 4.2.2 and in
section 4.2.3.
9HORFL W\'HFRGHU
In this line you can set the active velocity decoder. This line is only present if
both decoders OVD-01 and OVD-02 are installed. The velocity decoders are
abbreviated as described above in table 5.1.
9HORFLW\5DQJH
In this line you can set the velocity measurement range. The possible settings
depend on the velocity decoder selected. You will find information on setting
the velocity measurement range in section 4.2.2.
9HORFLW\)LOWHU
In this line you can set the cutoff frequency of the low pass filter. In position
OFF the upper frequency limit of the active velocity decoder is shown. You will
find information on setting the low pass filter in section 4.2.2.
'LVSODFHPH QW5DQJH
This line is only present if a displacement decoder is installed. In this line you
can set the displacement measurement range. The possible settings depend
on the displacement decoder installed. You will find information on setting the
displacement measurement range in section 4.2.3.
6LJQDO
This line shows the optical signal level as a bar display.
1RWH
If the PLL decoder is selected and the velocity measurement range 1 is set, it is not
possible to change to the HF decoder because this decoder does not have the velocity
measurement range available.
mm
s
----------
V
