2SHUDWLQJWKH9LEURPHWHU
0HQX)2& 86
RQO\ZLWK
2)9
This menu is only available in vibrometers with the sensor head OFV-303. In
this menu, the motor which moves the front lens is controlled using the
+ and - keys. The movement of the motor is shown on the display of the con-
troller with following symbols:
The bar in the lower line of the display shows the optical signal level.
6HWWLQJ0HDVXUHPHQW5DQJHVDQG)LOWHUV
&RQWUROOHU
You set the measurement ranges and filters via the display of the controller in
the menu SETTINGS (refer to section 5.9.3).
,QWHUIDFH
You can also set the measurement ranges and filters via the RS-232 interface
or the IEEE-488/GPIB interface on the back of the controller.
Adjusting the settings via the PC interfaces is described in appendix E.
'LVSOD\LQJWKH&RQILJXUDWLRQRIWKH&RQWUROOHU
The configuration of the controller is displayed in the menu CONFIG (refer to
section 5.9.3). You will find information about the velocity and displacement
decoders installed. Additionally the display shows whether the option
REMOTE FOCUS is installed and the configuration of the PC interfaces.
&RQILJXULQJW KH,QWHUIDFHV
The interfaces RS-232 and IEEE-488/GPIB can be configured via the display
of the controller in the menu CONFIG (refer to section 5.9.3 and section E.1).
< and > Motor is running slowly
<< and >> Motor is running quickly
|<< and >>| Motor has stopped at the end of the adjustment range
