Polytec OFV-512 - Filter Setting and Query

(
(,QWHUIDFH2SHUDWLRQ56DQG,(((*3,%
'LVSODFHPH QW'HFRGHU
Examples:
Command Description Answer
Answer with
ECHOON
AMPL? Queries the set measurement
range
Range number
(ASCII character)
1...7
(refer to table below)
AMPL1...
AMPL7
AMPL1...
AMPL7
Sets the corresponding measure-
ment range (refer to table below)
- AMPL1...
AMPL7
AMPL Loads the initialization settings
for the measurement range
(refer to command RENDCL)
-AMPL
RES Triggers the reset function of the
displacement decoder
-RES
Measurement range Range number
µ m/V OVD-10 OVD-20
0.5 - 0
1-1
8-2
20 3 3
80 4 4
320 5 5
1,280 6 6
5,120 7 7
$03/?Q If an OVD-20 is installed, the measurement range is set to
8 µ m/V.
$03/?Q The measurement range is set to 5,120 µ m/V.
$03/"?Q As an answer, a string with the number of the displacement
measurement range set is returned.
If the measurement range 320 µ m/V is selected, the controller
returns the string "5\n".
