POMCube iCAN NetZero Plus Series - Page 22

18
Rated
Frequency
60 Hz
Rated Current
32 A
42 A
45.8 A
52 A
100 A Pass Through/Bypass
Max. Output
Overcurrent
Protection
87.5A
170 A Pass Through/Bypass
Max Output
Fault
Current and
Duration
250 A Peak@49.8μs
PV Input
Max. Power of
PV
2 * 8.5 kWp
Voltage Range
175 Vdc ~ 450 Vd
MPPT Voltage
Range
175 Vdc ~ 380 Vdc
Full Load MPPT
Voltage Range
250 Vdc ~ 380 Vdc
MPPT Channels
2
Max. Current
2 * 26 A
Max Backfeed
Current
0A
Number of
Input
4
Battery
Input /
Output
Max. Power
12.5 kW
Voltage Range
360 ~ 584 Vdc
Max. Current
36 A
Protection
DC Disconnect
Yes
Rapid Shutdown
(RSD)
Yes
Anti-islanding
Protection
Yes
