Ponast KP 21 - Page 49

Automatic boiler for wood pellets
Instructions for installation and operation
48
1
Fan
42%
2 Temperature 80°C
3
Feeder 1 ON
9 s
4
Feeder 1 OFF
27 s
5
Advance Feeder 2
1 s
6 Run-in Feeder 2 3 s
7
Fall time
45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 4,5 9 90 1 3 30 45 80
P 2 8,5 9 48 1 3 34 45 80
P 3 12,0 9 31 1 3 38 45 80
P 4 13,5 9 27 1 3 42 45 80
P 5 15,0 9 23 1 3 46 45 80
P 6 13,5 9 27 1 3 42 45 80
9 El. Heating No
10
El. Ignition
No
1 Fan 64%
2 Temperature 80°C
3
Feeder 1 ON
9 s
4
Feeder 1 OFF
13 s
5 Advance Feeder 2 1 s
6 Run-in Feeder 2 3 s
7
Fall time
45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 7,5 9 55 1 3 30 45 80
P 2 13,5 9 27 1 3 45 45 80
P 3 20,0 9 15 1 3 53 45 80
P 4 22,5 9 13 1 3 64 45 80
P 5 25,0 9 10 1 3 75 45 80
P 6 22,5 9 13 1 3 64 45 80
9
El. Heating
No
10
El. Ignition
No
1 Fan 47%
2
Temperature
80°C
3
Feeder 1 ON
9 s
4
Feeder 1 OFF
22 s
5 Advance Feeder 2 1 s
6
Run-in Feeder 2
3 s
7
Fall time
45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 5,1 9 85 1 3 30 45 80
P 2 9,4 9 43 1 3 36 45 80
P 3 13,6 9 27 1 3 43 45 80
P 4 15,3 9 22 1 3 47 45 80
P 5 17,0 9 20 1 3 51 45 80
P 6 15,3 9 22 1 3 47 45 80
9
El. Heating
No
10 El. Ignition No
1
Fan
51%
2
Temperature
80°C
3
Feeder 1 ON
9 s
4 Feeder 1 OFF 10 s
5 Advance Feeder 2 1 s
6
Run-in Feeder 2
3 s
7
Fall time
45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 8,7 9 47 1 3 30 45 80
P 2 16,0 9 22 1 3 36 45 80
P 3 23,2 9 12 1 3 43 45 80
P 4 26,1 9 10 1 3 51 45 80
P 5 29,0 9 8 1 3 57 45 80
P 6 26,1 9 10 1 3 51 45 80
9
El. Heating
No
10 El. Ignition No
KP 10 Feeder 1 with spiral path 38 mm, Burner No.20
8
KP 20 Feeder 1 with spiral path 38 mm, Burner No.20
8
KP 11 Feeder 1 with spiral path 38 mm, Burner No.20
8
KP 21 Feeder 1 with spiral path 38 mm, Burner No.20, Fan 30-108
8
