Ponast KP 21 - Setting Control Unit from Productions

Automatic boiler for wood pellets
Instructions for installation and operation
47
Table 6
Setting Control Unit from productions
1
Fan
42%
2
Temperature
80°C
3
Feeder 1 ON
5 s
4
Feeder 1 OFF
45 s
5
Advance Feeder 2
1 s
6
Run-in Feeder 2
5 s
7
Fall time
45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 4,5 3 80 1 5 30 45 80
P 2 8,3 5 75 1 5 34 45 80
P 3 12,0 5 50 1 5 38 45 80
P 4 13,5 5 45 1 5 42 45 80
P 5 15,0 5 38 1 5 46 45 80
P 6 13,5 5 45 1 5 42 45 80
9 El. Heating No
10
El. Ignition
N
o
1 Fan 64%
2 Temperature 80°C
3 Feeder 1 ON 5 s
4 Feeder 1 OFF 25 s
5 Advance Feeder 2 1 s
6 Run-in Feeder 2 5 s
7 Fall time 45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 7,5 5 90 1 5 30 45 80
P 2 13,5 5 45 1 5 45 45 80
P 3 20,0 5 29 1 5 53 45 80
P 4 22,5 5 25 1 5 64 45 80
P 5 25,0 5 22 1 5 75 45 80
P 6 22,5 5 25 1 5 64 45 80
9 El. Heating No
10
E
l.
I
gn
i
t
i
on
N
o
1 Fan 75%
2 Temperature 80°C
3 Feeder 1 ON 10 s
4 Feeder 1 OFF 20 s
5 Advance Feeder 2 1 s
6 Run-in Feeder 2 5 s
7 Fall time 45 min
Programs kW Feeder 1 ON Feeder 1 OFF Advance Feeder2 Run-in Feeder2 Fan Fall time Temperature
P 1 14,5 10 80 1 5 30 45 80
P 2 26,5 10 40 1 5 50 45 80
P 3 39 10 24 1 5 60 45 80
P 4 44,5 10 20 1 5 75 45 80
P 5 49 10 17 1 5 90 45 80
P 6 39 10 24 1 5 60 45 80
9 El. Heating No
10
E
l.
I
gn
i
t
i
on
N
o
KP 10 Feeder 1 with endless screw, Burner No.20
8
KP 20 Feeder 1 with endless screw, Burner No.20
8
KP 50 Feeder 1 with endless screw, Burner No.20
8
