Changing presser foot
Foot release level
Recess
Foot holder snaps
Be sure needle is in the up position. Raise presser foot lever.
Snap-on presser foot
1. Raise foot release lever to remove the foot.
2. Place the desired foot on the needle plate aligning needle
holes.
3. Lower the presser foot lever so that the foot holder snaps
on the foot.
Auxiliary box
Knocking out
As shown in diagram, leftwards pull the auxiliary box and
withdraw it from machine. The auxiliary box may be
disassembled as free arm or as auxiliary desk for sewing.
Installation
Push the auxiliary box into the machine and fully insert and
fix the protrusion into the fixing hole of auxiliary box.
Auxiliary box
Protrusion
Fixing hole
Stitch selector and indication
1. To select a stitch, be sure needle is out of fabric at its
highest position.
2. Then turn the selector until the required stitch is indicated
by the symbol.
3
