POOLiN EOC565 - Winding Bobbin

Winding bobbin
1. Removing bobbin case
Remove the accessories box from the machine. Raise the
needle to its highest position by turning hand wheel
manually towards you.
Bobbin access cover
Hold cop latch of the bobbin case and take out the bobbin
case from shuttle race.
Bobbin case
Cop latch
2. Removing bobbin
After opening the cop latch, the bobbin as shown in
diagram will drop out from bobbin case.
Bobbin
4
3
5
