© 2017 PoolPak LLC. All rights reserved. ComPak
AUXILIARY AIR HEAT TEST
___ 1. If unit is equipped with a gas-fired furnace for auxiliary air heat, verify that a regulation device is
present. Use a manometer to verify that the entering gas pressure is not exceeding the max on the
nameplate of the furnace. Turn on all gas valves, both inside the ComPak and external. On Modine
furnaces, turn on the toggle switch for the electronic gas valve.
___ 2. If unit is equipped with an duct-mounted electric coil for auxiliary air heat, verify proper field wiring,
disconnect size and fuse or breaker size. Turn on disconnect.
___ 3. Place the controller into manual output test mode by setting the following: Press the PRG (
) button.
The screen will show “Main Menu – Status Screens”. Press the UP ARROW () to select “Main Menu
– Service” and then press the ENTER (↵) button. “Password Required” is displayed. Use the UP
ARROW () to change the number to: 0005 and press the ENTER (↵) button. The display will show
“Main Menu – Service – I/O Configuration”.
Press the UP ARROW () to select “Main Menu – Service – Manual Mode” and then press the
ENTER (↵) button. “Password Required” is displayed. Use DOWN ARROW () to change the number
to: 9995 and press the ENTER (↵) button. The display will show “Main Menu – Service – Manual Mode
– Demand Control”. Press the UP ARROW () to select “Main Menu – Service – Manual Mode –
Digital Outp Ctl” and then press the ENTER (↵) button. The screen will display “Digital Outp Ctl 1 –
Improper use may cause equipment damage! ESC to exit”.
Press the DOWN ARROW () so that “Digital Outp Ctl 2” is displayed. Press the ENTER (↵) button to
move the cursor next to “AuxHt 1 Output”. Press the UP ARROW () to change it from AUTO to ON
and press ENTER (↵).
___ 2. The Auxiliary Air Heat 1 output should turn on. Verify if auxiliary air stage one control is on. This could
be an electric heat contactor, a furnace ignition or a hot water valve actuator.
Did the Aux Air Heat 1 turn on? YES or NO
___ 3. Repeat this process if there is a second stage of Auxiliary Air Heat.
Did the Aux Air Heat 2 turn on? YES or NO
___ 4. If aux air heat worked properly, change the output(s) back to AUTO. If not contact PoolPak Service.
COMPRESSOR STARTUP
Note: Do not open the ball valves for the air-cooled or water-cooled condenser line set.
___ 1. Record the voltage on the line side of the compressor contactor:
Compressor 1A 1-2 ____V 1-3 ____V 2-3 ____V
___ 2. Press the PRG (
) button. The screen will show “Main Menu – Status Screens”. Press ENTER (↵)
then press the DOWN ARROW () and record the following data:
SPACE TEMP: °F OUTSIDE TEMP (Economizer units only): °F
SPACE RH: %
SPACE DEWPOINT: °F POOL TEMP (AW models only) °F
