34
15-3/4 in. (400 mm)
90°
20° - 30°
PUSH STICK CONSTRUCTION
• Use good quality plywood or solid wood
• Use 1/2 in. (13 mm) or 3/4 in. (19 mm) material
• Push stick MUST be thinner than the width of
material being cut
Drill Hole for
Hanging
Notch for Prevent
Hand from Slipping
Cut Here to Push 1/2 in.
(13 mm) Wood
Cut Here to Push 3/4 in.
(19 mm) Wood
PUSH STICK PATTERN
