35
PARTS LIST
10 IN. (254 MM) JOBSITE TABLE SAW
PARTS LIST FOR JOBSITE TABLE SAW
I.D. Description Size Qty I.D. Description Size Qty I.D. Description Size Qty
08VH CORD CLAMP 1 0KF6 CR. RE. PAN HD. SCREW
M4*0.7-8
2 2T6D
ANIT-KICKBACK PAWL ASS’Y
1
09XJ COMPRESSION SPRING 1 0KJ0 CAP HD. SQ.NECK BOLT
M6*1.0-16
2 2TJ9 FLAT WASHER
φ6*13-0.5
2
0B9M STRAP 1 0KJM CAP HD. SQ.NECK BOLT
M6*1.0-30
1 2TLZ POINTER BRACKET 1
0BA3 ANCHOR BLOCK 1 0KMS HEX. NUT
M6*1.0 T=5
4 2TUY BLADE GUARD ASS’Y 1
0BAC SET NUT 1 0KQJ CROWN NUT
M8*1.25 T=12.5
2 2UZU SPACER 1
0BAE ARBOR COLLAR 1 0KQW LOCK NUT
M5*0.8 T=5
1 2V3E BLADE GUARD(RIGHT) 1
0BAU SUPPORTING PLATE 1 0KQX NUT
M6*1.0 T=6
2 2V3F BLADE GUARD(LEFT) 1
0BB2 LOCATING RING 1 0KQY LOCK NUT
M5*1.25 T=8
1 2WVS EXTENTION WING (REAR) 1
0BC2 LOCATION SEAT 2 0KRX
HEXAGON NUT AND FLAT WASHER
M6*1.0
2 2WVT REAR SIDE COVER 2
0GCM BEVEL GEAR 2 0KSM STRAIN RELIEF 1 2WVU FRONT SIDE COVER (L) 1
0GCT PIVOT-SUPPORT 2 0KTK STRAIN RELIEF 2 2WVV FRONT SIDE COVER (R) 1
0J3P HEX WRENCH 1 0KTR CABLE CLAMP 1 2WVW RAIL (FRONT) 1
0J4D FLAT WASHER
φ5*10-1
4 0KWU LEAD WIRE ASS’Y 1 2WVX RAIL (REAR) 1
0J4E FLAT WASHER
φ6*13-1
1 0LSL CIRCUIT BREAKER SWITCH 1 2WW0 RETAINING CLIP 1
0J4P FLAT WASHER
φ8*16-1.4
1 0SZY SLIDING BASE ASS’Y 1 2WW1 BODY 1
0J4T FLAT WASHER
φ10*16-1
1 0SZZ SLIDING BASE ASS’Y 1 2WW2 DUST COLLECTOR #6 1
0J5A FLAT WASHER
φ5*16-2
1 0T01 RUBBER PAD 1 2WW3 CLAMPER BRACKET 1
0J5E FLAT WASHER
φ8*15-1
2 10JN SET PLATE 2 2WW4 ANCHOR BLOCK 1
0J6K FLAT WASHER
φ6*30-4
1 10JR LOCATING BAR 1 2WW5 HEIGHT WORM 1
0J6P FLAT WASHER
φ6*16-2
1 10JS ROLL PIN 1 2WW6 CLAMP BAR 1
0J6T FLAT WASHER
3/16*3/4-1/16
4 10JU ANCHOR PLATE 2 2WW7 CLAMP 1
0J6V FLAT WASHER
3/16*3/8-0.022
4 10JV LOCATING BAR 1 2WW8 HEIGHT REGULATING BOLT 1
0J7T FLAT WASHER
1/4*29/32-1/16
1 10K2 BUSH 2 2WW9 RIVING KNIFE 1
0J8D FLAT WASHER
3/8*3/4-5/64
2 10K4 PARALLEL PIN 2 2WXE MOTOR ASS’Y 1
0J92 SPRING WASHER φ5 4 10K5 HEX. SOC. HD. CAP BOLT
M5*0.8-8
2 2X21 SWITCH KEY 1
0J95 SPRING WASHER φ6 1 20GJ BRACKET STOP 1 2X22 ROCKER SWITCH ELEMENT 1
0JAE EXTERNAL TOOTH LOCK WASHER φ4 2 213B SPACER
40*5
4 2X23 ROCKER SWITCH 1
0JAF EXTERNAL TOOTH LOCK WASHER φ5 1 21CH
CR.RE. PAN HD. SCREW & WASHER
M5*0.8-10
1 2X5J SWITCH BOX 1
0JCA SPRING PIN
3-24
1 21CX FOLLOWER PLATE 1 2X69 RIP FENCE ASS’Y 1
0JE8 C-RING 1 239T
CR.RE. PAN HEAD TAPPING & WASHER SCREW
M5*0.8-16
4 2X6B HAND WHEEL ASS’Y 1
0JED C-RING 1 25W7 HEX.SOC. HD.CAP SCREW
M5*0.8-12
1 2X6C HAND WHEEL ASS’Y 1
0JX7 HEX. SOC. SET SCREW
M6*1.0-6
2 262S POWER CORD CLAMP 2 2X6D BODY SHELL 1
0K2B HEX SOC. HD. CAP SCREW
M6*1.0-16
4 275E EXTENSION TUBE 2 2X6E MITER GAUGE ASS’Y 1
0K3E CR.RE. PAN HD. SCREW & WASHER
M5*0.8-10
1 275F LOCATION SEAT 2 2X6N SWITCH BOX ASS’Y 1
0K3H CR.RE. PAN HD. SCREW & WASHER
M6*1.0-12
1 275R LOCATION SEAT 1 2X6R LOCKING HANDLE ASS’Y 1
0K4T CR.-RE. TRUSS HD. SCREW
M5*0.8-20
1 28BN COVER 1 2X6V WRENCH HEX. 1
0K6U CR.-RE. TRUSS HD. SCREW
M4*0.7-8
1 28C3 RACK 1 2X74 WRENCH 1
0K72 CR.-RE. TRUSS HD. SCREW
M5*0.8-12
1 28EX NEEDLE POINTER 1 2XJ6 POWER CABLE 1
0K77 CR.-RE. TRUSS HD. SCREW
M6*1.0-23
2 28KD TILT POINTER
#GM
1 2XLH HEX.SOC. HD.CAP BOLT
M6*1.0-16
1
0K7K CR. RE. ROUND WASHER HD. SCREW
M6*1.0-12
2 28PA KNOB 1 2XP1 TABLE #GL 1
0K8C CR. RE.COUNT HD. TAPPING SCREW
M4*18-10
4 293H PUSH STICK 1 2XRC EXTENSION TABLE #GL 1
0K9T HEX. HD. TAPPING SCREW
M5*16-16
4 29R9 CUSHION 1 2XSH LABEL 1
0K9U HEX. HD. TAPPING SCREW
M5*16-25
4 2CFE HANDLE 1 2XSJ LABEL 1
0KA4 CR.RE. PAN HD. TAPPING SCREW
M4*16-16
2 2CFL LOCATING BAR 1 2XSK WARNING LABEL 1
0KB3 CR.RE. PAN HD. TAPPING SCREW
M4*18-8
2 2CFV HANDLE
#GL
1 2XSL STICKER 1
0KBA CR.RE. PAN HD. TAPPING SCREW
M5*16-12
2 2CS2
BEVEL ANGLE ADJUSTMENT ASS’Y
1 2XSM LABEL 1
0KBQ CR.RE. PAN HD. TAPPING SCREW
M5*16-10
1 2D6H HEX.SOC. SET SCREW
M6*1.0-6
6 2XSQ SCALE 1
0KC8 CR. RE. TRUSS HD. TAPPING SCREW
M4*16-16
5 2EA5 RACK(FRONT) 1 2Y01 POWER CABLE ASS’Y 1
0KCA CR. RE. TRUSS HD. TAPPING SCREW
M5*12-12
2 2J6Z HEX.SOC. HD.CAP BOLT
M5*0.8-10
2 2YBD WARNING LABEL 2
0KCX
CR. RE. PAN HD PLAIN WASHER TAPPING SCREW
M5*0.8-10
6 2PHV
CR.RE. PAN HD. TAPPING SCREW
M5*16-12
6 2YFX INSTRUCTION MANUAL 1
0KCY
CROSS-RECESSED PAN HD PLAIN WASHER TAPPING SCREW
M5*0.8-12
4 2PV7
HEX.SOCKET HD.CAP SCREWS
M5*0.8-18
3 2YQ2 BLADE 1
0KCZ
CROSS-RECESSED PAN HD PLAIN WASHER TAPPI
M5*0.8-16
2 2QHH DUST GUARD 1 2Z08 PLUNGER HOUSING ASS’Y 1
0KDJ CR. RE. PAN HD. SCREW
M5*0.8-12
1 2RVE INSERT
#GM
1 2Z2M SCALE ASS’Y 1
0KDU CR. RE. PAN HD. SCREW
M6*1.0-12
2 2RXQ SPACER 2 2Z2W LEAD WIRE ASS’Y 1
