Porter-Cable PCB375SS - PRODUCT SPECIFICATIONS; MOTOR; BLADE; TABLE AND ACCESSORIES

2
2013/07
TABLE OF CONTENTS
SECTION PAGE
PRODUCT SPECIFICATIONS
.................................................................................................................... 2
CALIFORNIA PROPOSITION 65
................................................................................................................. 3
SAFETY GUIDELINES - DEFINITIONS
...................................................................................................... 3
POWER TOOL SAFETY
............................................................................................................................. 4
SCROLL SAW SAFETY
...............................................................................................................................
5
ELECTRICAL REQUIREMENTS AND SAFETY ......................................................................................... 6
TOOLS NEEDED FOR ASSEMBLY ............................................................................................................
8
CARTON CONTENTS ................................................................................................................................. 8
UNPACKING YOUR SCROLL SAW
........................................................................................................... 9
KNOW YOUR SCROLL SAW
..................................................................................................................... 10
GLOSSARY OF TERMS
.............................................................................................................................. 11
ASSEMBLY AND ADJUSTMENTS
.............................................................................................................. 12
OPERATION
............................................................................................................................................... 17
MAINTENANCE
.......................................................................................................................................... 21
ACCESSORIES AND ATTACHMENTS....................................................................................................... 22
TROUBLESHOOTING GUIDE
..................................................................................................................... 23
PARTS LIST................................................................................................................................................. 24
WARRANTY
................................................................................................................................................. 28
To avoid electrical hazards, re hazards or damage to the tool, use proper circuit protection. Use a separate electrical
circuit for your tools.
The scroll saw is wired at the factory for 110-120 Volt operation. It must be connected to a 120V,1.6 Amp branch
circuit and use a 1.6 Amp time delay fuse or circuit breaker. To avoid shock or re, replace power cord immediately if it
is worn, cut or damaged in any way.
PRODUCT SPECIFICATIONS
MOTOR TABLE
Power Source…………........... 120 V, 60 Hz, 1.6 Amp Size................................. 20 in. x 12-5/8 in.
Speed.................…………...... 500-1500 RPM (506 mm × 322 mm)
Speed Control.………............. Electric Tilt................................... 45° Left ; 15° Right
BLADE SAWDUST BLOWER Yes
Blade Length.......................... 5 in. WORK LIGHT LED
Type…..........…………………. Pin-end or Plain-end
Depth of Throat....................... 18 in. (457 mm)
Blade Stroke…......….............. 3/4 in. (19 mm)
Depth of 90° Cut..................... 2-1/4 in. (57 mm)
Depth of 45° Cut, Left ………. 1-1/4 in. (32 mm)
Depth of 15
° Cut, Right .......... 2-1/4 in. (57 mm)
Printed in China
WARNING
!
