24
18 IN. (457 MM) VARIABLE SPEED SCROLL SAW
PARTS LIST
I.D. Description Size Q’ty I.D. Description Size Q’ty
0A98 COMPRESSION SPRING 1 2ECB WIRE ROPE ASS’Y 1
0AM3 WASHER 1 2EZ1 CR. RE. TRUSS HD. SCREW M5*0.8-10 2
0C10 PLAIN-END BLADE 5” 1 2FBG CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 2
0C12 PIN-END BLADE 5” 1 2GBJ CR. RE. PAN HD. SCREW M5*0.8-12 3
0DEJ RUBBER PADS 3 2XRP ROCKER SWITCH 1
0DF6 BELLOWS 1 2XZL TENSION HANDLE 1
0DF8 PLUG HOUSING 1 2XZP PLUNGER HANDLE 1
0ES8 PVC HOSE 1 2Y6G FOLLOWER PLATE 1
0HFW BOLT CLAMP 1 2YPG CAUTION LABEL 1
0J3M HEX. WRENCH 3 mm 1 2YPJ CAUTION LABEL 1
0J4E FLAT WASHER φ6*13-1 2 2YPM WARNING LABEL 1
0J4U FLAT WASHER φ6*18-1.5 3 36CM BASE GROUP 1
0J66 FLAT WASHER φ4*10-1 2 36CP BASE GROUP 1
0JAF EXTERNAL TOOTH LOCK WASHER φ5 1 36CV BOTTOM ARM ROCKER 1
0JAZ WAVE WASHER 2 36CW UPPER ARM ROCKER 1
0JB0 WAVE WASHER 1 36CX SWITCH BOX COVER 1
0JC8 SPRING PIN 2 36CY SWITCH BOX GROUP 1
0JCH SPRING PIN 2 36CZ TABLE 1
0JDA SPRING PIN 1 36D1 BLADE BOX 1
0JMM O-RING 2 36D2 RETAINING CLIP 1
0JPG HEX. HD. BOLT M6*1.0-30 1 36D3 BODY ASS’Y 1
0JUD HEX. SOC. HD. CAP BOLT M5*0.8-20 3 36E9 MOTOR COVER 1
0JUL HEX. SOC. HD. CAP BOLT M6*1.0-20 1 36EB HOUSING RIGHT 1
0JUP HEX. SOC. HD. CAP BOLT M6*1.0-35 1 36EC HOUSING 1
0JXR HEX. SOC. SET SCREW M8*1.25-8 1 36EG ADJUST BOLT 1
0JZB HEX. SOC. SET SCREW M4*0.7-6 1 36EJ SIDE COVER 1
0K0T HEX. HD. SCREW AND WASHER M8*1.25-20 8 36EM DUST COLLECTOR 1
0K23 HEX SOC. HD. CAP SCREW M6*1.0-16 3 36EP SWITCH BOX COVER 1
0K25 HEX.SOCKET HD.CAP SCREWS M5*0.8-20 1 36ER PUSH BUTTON 1
0K56 CR. RE. COUNT HD. SCREW M5*0.8-12 4 36EU BRACKET-TILT 1
0K6X CR.-RE. TRUSS HD. SCREW M4*0.7-6 1 36EW SIDE COVER 2
0K71 CR.-RE. TRUSS HD. SCREW M5*0.8-8 2 36F1 CLAMP HANDLE 1
0K72 CR.-RE. TRUSS HD. SCREW M5*0.8-12 2 36F2 SPECIAL BOLT 2
0K7F CR. RE. ROUND WASHER HD. SCREW M5*0.8-8 4 36F3 LOCKING ROD 1
0K7X CR. RE. TRUSS HD. ROUND NECK SCREW M6*1.0-10 1 36F6 GUIDE BLOCK 1
0KA5 CR.RE. PAN HD. TAPPING SCREW M4*16-20 1 36FA SHAFT-PIVOT 1
0KBA CR.RE. PAN HD. TAPPING SCREW M5*16-12 2 36FE SPEED CONTROL BUTTON 1
0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 3 36FH RETAINING CLIP ASS’Y 1
0KDK CR. RE. PAN HD. SCREW M5*0.8-16 1 37US STRAIGHT LINKAGE BAR 1
0KDV CR. RE. PAN HD. SCREW M6*1.0-16 10 37VC ECCENTRIC 1
0KFE CR. RE. PAN HD. SCREW M5*0.8-6 1 3877 TRUNNION BRACKET 1
0KMS HEX. NUT M6*1.0 T=5 1 3C92 AIR DUCT ASS’Y 1
0KQW LOCK NUT M5*0.8 T=5 1 3C93 MOTOR ASS’Y 1
0KQX NUT M6*1.0 T=6 3 3C96 LED WORK LIGHT ASSEMBLY 1
0LN4 WIRE CONNECTOR 1 3C9W CONTROLLER ASS’Y 1
22A4 LOCKING CABLE TIE 2 3C9Y INSERT 1
22XF CR.RE. PAN HD. TAPPING SCREW M3*20-15 1 3CA3 LEAD WIRE ASS’Y 1
23CT CR.RE. PAN HD. TAPPING SCREW M5*12-15 2 3CA4 LEAD WIRE ASS’Y 1
24ZT HEX.SOCKET HD.CAP SCREWS M4*0.7-12 1 3CB9 VARIABLE RESISTOR ASSEMBLY 1
25B1 CR.-RE. TRUSS HD. SCREW M5*0.8-25 1 3CCB HOLDER BLADE ASS’Y 2
25ZQ SPACER 1 3CCE BEARING SEAT ASS’Y 1
25ZR BRACKET STOP 1 3CVE ROLL PIN 1
263T CROWN NUT M6*0.75 , T=5 1 3CVM SUPPORT ROD 1
263W SQUARE NUT M6*0.75 , T=5 1 3CVQ ANCHOR PLATE 1
27XG ROLL PIN 1 3CX0 CR.RE. PAN HD. TAPPING SCREW M3*24-8 1
2A4U TURNTABLE 1 3EPH INSTRUCTION MANUAL 1
2A60 SPRING GUARD 1 3EPN TRADEMARK LABEL 1
2E63 ROCKER SWITCH 1 3EPP CAUTION LABEL 1
2EBB CR. RE.COUNT HD. TAPPING SCREW M5*12-16 2 3EPQ TILTING SCALE 1
2EBZ TURNTABLE COVER 6# 1 3EPR WARNING LABEL 1
2EC3 PLATE COVER 1 3EPS CAUTION LABEL 1
2EC4 GUIDE HOLDER 6# 1 HARDWARE BAG
2EC5 COVER 6# 1 3CWM B. BLADE ASSEMBLY 1
PARTS LIST
