8 - ENG
3. Insert a stick of cleats or staples into the magazine. NOTE: Use only PORTER-CABLE
approved fasteners.
4. Push the detent to unlock the pusher. Slide pusher to the fully forward position.
FIG. 4 FIG. 5
USING THE TOOL (FIG. 1, 6)
Regarding Use of this Tool to Install Prefinished Flooring
The PCFP12561 was designed for installing both unfinished and pre-finished hardwood
flooring. Care must be used however when installing pre-finished flooring to ensure that the
finish is not damaged by the tool. It is recommended that the tool be inspected for damage
[especially the guide plate (C)] and tested on a sample section to be certain that the tool and
technique of use do not mar the finish. This procedure should be followed before each job
due to variations in flooring and tool condition.
• It is not necessary to hit the rubber cap hard to activate it. Never hit the tool hard
with excessive force, as this will damage the tool.
• Do not use the tool to position the flooring strips.
• Do not use the metal end of the mallet to strike the rubber cap, use the rubber end
only.
1. Complete all steps of Preparing The Tool before using the tool.
2. Position and closely fit together (rack) the flooring strips using the metal end of mallet(F).
B
C
FIG. 6
F
