8
POWER ADAPTOR
ITEM REQUIREMENT
Input voltage 100 V AC ~ 240 V AC
Input frequency 50 ~ 60 HZ
Input current 1.8 A MAX. @ 115 V AC
Output voltage + 24 V DC
Output power 50 W
Static load 0 A ~ 2.08A
Output regulation + / - 5 %
EMI standards VDE – A, FCC – A, VCCI – A
MULTIPLE INTERFACE ISSUE
For model PP-6900/6901, there is only 1 connector for host connection
through USB. For PP-6900P/6901P, there are 2 connectors for host
connection: USB and in addition to parallel port. For PP-6900S/6901S,
there are 2 connectors for host connection: USB Port and in addition to the
serial port. For PP-6900L/6901L, there are 2 connectors for host
connection: USB and in addition to the LAN port. Please always connect
only one interface at a time. Simultaneous multiple host connections
could result in unexpected results!
To get the detailed information on
※
※※
※
PP-6900/6901, please check this model
from Posiflex Global Website (
http://www.posiflex.com/en-
global/Download/download).
