POSIFLEX PP-6900 - Rear View and I;O Ports; Quick Start-Up Guide; Loading the Paper Roll

3
Rear View
QUICK START-UP
LOADING A PAPER ROLL
While loading a paper roll for PP-6900/6901, please
do NOT power ON your printer.
Start to load a paper roll according to the following steps.
Frame Ground Screw
USB Port
P
eripheral Port
P
ower Connector
Serial Port
Serial Adaptor
Fixation Screw
(I/O Area for PP-6900S/6901S)
Parallel Port
Parallel Adaptor
Fixation Screw
Wi-Fi Indicator
Reset Button
LAN Port
LAN Adaptor
Fixation Screw
(I/O Area for PP-6900L)
Reset
Button
(I/O Area for PP-6900P)
(I/O Area for PP-6900W/6901W)
