GAM Quick Installation Guide
Positron Access Solutions 19 Document 180-0211-001 R01
You are now ready to connect the AC-DC Power supply included as part of your
GAM-4-MX / GAM-8-MX kit.
Step 9: The 12Vdc connector is located at the
top right corner of the GAM enclosure. Pull on
the male power connector that ships pre-
installed in unit.
Step 10: using 18 AWG wire, insert the power
cable through the rightmost cable gland. You
can then connect the 12Vdc power pair to the
male power connector and tighten with a small
flat screwdriver.

Positron GAM-8-MX Specifications

General

Brand	Positron
Model	GAM-8-MX
Category	Wireless Access Point
Language	English
