[n = 01h ], [ m = 03h ]
To turn off all the annunciators:
[n = 00h ], [ m = 00h ]
Above commands relating decimal point, comma, semicolon, and
※
annunciator may not be available due to hardware limit of display tube.
4.1.3 UTC Standard Command Mode
Command Hex Function Description
BS 08 Back space
HT 09 Horizontal tab
LF 0A Line feed
CR 0D Carriage return
DC0 p 10 p Move cursor to specified position,
0p39≦≦
(Please refer Row Character Position
Chart )
DC1 11 Over write display mode
DC2 12 Vertical scroll mode
DC3 13 Cursor on
DC4 14 Cursor off
ESC d 1B 64 Change to UTC enhanced mode
US 1F Clear display
Row Character Position Chart (Decimal)
Row1 0 1 2 3 4 567891011121314 15 16 17 1819
Row2 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39
Row Character Position Chart (Hex)
Row1 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 10 11 12 13
Row2 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 20 21 22 23 24 25 26 27
