POSX XP8200 - DSP800 Command Mode

4.1.7 DSP800 Command Mode
Command Hex Function Description
EOT SOH I
n ETB
04 01 49 n 17 Select international character set
( Please refer International Font Set Table )
EOT SOH P
n ETB
04 01 50 n 17 Move cursor to specified position
49n88≦≦
EOT SOH C
n m ETB
04 01 43 n m 17 Clear display range from n position to m
position and move cursor to n position
49nm88≦≦ ≦
EOT SOH S
n ETB
04 01 53 n 17 Save the current displaying data (40
characters) to n’th layer for demo display
1n3 ≦≦ ( n specify the layer 1, 2, or 3 )
EOT SOH D
n m ETB
04 01 44 n m 17 Display the saved data
1 n 3 ( n specify the layer 1, 2, or 3 )≦≦
“m” can be ignored
EOT SOH A
n ETB
04 01 41 n 17 Brightness adjustment
1n4≦≦
EOT SOH =
n ETB
04 01 3D n 17 Select peripheral device
n=1, printer ; n=2, display
EOT SOH %
ETB
04 01 25 17 Initialize display
* International Font Set Table
n (Hex) International Font Set
30h
31h
32h
33h
34h
35h
36h
37h
38h
39h
3Ah
XXh
U.S.A.
FRANCE
GERMANY
U.K.
DENMARK I
SWEDEN
ITALY
SPAIN
JAPAN
NORWAY
DENMARK II
SLAVONIC/RUSSIA
RUSSIAN
GREEK
CZECH
LATIVAIN
