2.0 Troubleshooting
START
Make sure the gas supply
is turned ON and check if
other gas appliances are
operating (e.g. fire, cooker).
If no gas, consult your
supplier.
Is the ON/OFF/Reset
Select Switch in the
( ) position ?
Is the ( ) or ( ) light
on and the ( ) on ?
Check electricity to the
boiler is switched on.
Is the display lit ?
Display
Central Heating
Indicator
Domestic Hot
Water Indicator
Burner On
Indicator
Boiler operating satisfactorily.
2
1
0
4
3
bar
Is the Central Heating
System Pressure between
1 and 2.5 bar ?
If the reading falls below 1 bar
repressurise the system as
described in section 3.0.
Does the display show an
error code e.g. E133, E110 ?
Boiler not working
NO
NO
YES YES
YES
NO
Turn the ON/OFF/Reset
Selector Switch to Reset.
Error Code E119 showing
low pressure.
NO
YES
YES
NO
If boiler does
