Pottinger CAT NOVA 310 - Gearing on the Conditioner Drive 1); Gearing on the Swath Former Drive 1)

- 17 -
1)
optional equipment
(362) 9700-GB WARTUNG
MAINTENANCE GB
TD 45/94/22
Oil Level
A
Gearing on the conditioner drive
1)
Check oil level: Once a year under normal operating conditions,
however after 100 ha. at the latest.
Oil level: The oil level (0.25 litre SAE 90) is correct when it reaches
this screw.
Oil change: After 300 ha. at the latest.
1. Remove drain plug (A), drain old oil and dispose of properly.
2. Refill oil at the "Oil Level" screw (0.25 litre SAE 90).
Gearing on the Swath Former Drive
1)
0.4 litre SAE 90
Oil change: After 300 ha. at the latest.
TD 69-97-14
